Crestron CEN-SWPOE-ULTRA-12 12 Port Ultra PoE Managed Switch

It is a 12 port managed Ethernet switch from the NETGEAR AV range, designed to make Crestron AV-over-IP products easier to integrate. It has eight Gigabit ports with PoE++, two Gigabit ports without PoE and two 10 Gigabit Base-X SFP+ ports, with Layer 2 and Layer 3 managed switching.

Ports 1 to 8 support PoE++ to IEEE 802.3bt Type 3 and can supply up to 90 W per port, with 720 W in total across the switch. Crestron lists power consumption at maximum PoE as 837.7 W. Ports 9 and 10 carry data only.

Yes. The switch has selectable DM NVX and DM NAX AV-over-IP profiles. It also includes IGMPv3 and MLDv2 snooping with an IGMP querier, VLANs, IEEE 1588 PTPv2 and LLDP support as part of its Lite Layer 3 feature package.

Ports 11 and 12 are 10 Gigabit Base-X SFP+ ports. They accept transceiver modules so the switch can connect to a fibre network. Each has a green LED that shows an active connection, and the LED is repeated on the front and rear panels.

It can be freestanding or mounted in 1U of a 19-inch rack using reversible rack ears. The fan-cooled metal chassis measures 43.2 mm high, 440 mm wide and 257 mm deep. Power, fan and PoE MAX LEDs are repeated on the front and rear panels, and a recessed button handles reboot or factory reset.

Crestron asks its dealers to give the price of the CEN-SWPOE-ULTRA-12 directly rather than publish it online. Add it to your quote list and we will send you a written quote, with delivery, and installation and programming if you need them.

Yes. 1Install is an authorised Crestron Elite Partner with offices in Skerries, Co. Dublin and Cork. We can supply the CEN-SWPOE-ULTRA-12 on its own, or install, set up and programme it as part of your system. Installation visits are €440 for 4 hours or €880 for a full day, plus VAT and travel.

Yes. Everything we supply is new, genuine Crestron with Crestron's standard warranty. If the CEN-SWPOE-ULTRA-12 develops a fault, contact us and we will handle the claim with Crestron. If we installed it, our workmanship is guaranteed for the lifetime of the system.

We order Crestron for each quote, so availability depends on Crestron's stock at the time. We check it before we quote and put the expected delivery date on your quote, so you know where you stand before you pay.

Yes. We supply Crestron to end users, with or without installation. If you are not sure it suits your system, send us the part numbers you already have and we will check.
