Crestron HD-MD4X2-4KZ 4x2 4K60 4:4:4 HDR HDMI Switcher

It is a 4x2 4K60 4:4:4 HDR AV switcher with four HDMI inputs and two HDMI outputs. It supports HDR10, HDR10+ and Dolby Vision, switches inputs automatically, manages EDID and is HDCP 2.3 compliant, with CEC device control and native Crestron control via Ethernet.

The HD-MD4X2-4KZ-E is PoE powered, complying with IEEE 802.3at Type 1 (802.3af compatible) Class 0, or it can run from the optional PW-2407WU 24 VDC power pack, which is sold separately. Typical power consumption is 12 W.

Yes. HDMI audio can be de-embedded to a stereo 2-channel analogue line output. Its volume adjusts from -80 dB to +20 dB with mute, mono and stereo options, and the analogue stage offers a 20 Hz to 20 kHz frequency response within ±0.5 dB and a signal to noise ratio above 95 dB.

The HDMI inputs and outputs support HDR10, HDR10+, Dolby Vision, Deep Color and up to 4K60 4:4:4. At 4K and 60 Hz the switcher carries 4:4:4 at 24 bit or 4:2:2 at 36 bit, and 2560x1600 and 1080p at 60 Hz run at 4:4:4 with 36 bit colour depth.

It supports native Crestron control via Ethernet, a built-in web interface and XiO Cloud connectivity, and it includes enterprise-grade security. Inputs can switch automatically, and connected devices can be controlled via CEC, so the switcher suits both programmed Crestron rooms and simpler set-ups.

Crestron asks its dealers to give the price of the HD-MD4X2-4KZ directly rather than publish it online. Add it to your quote list and we will send you a written quote, with delivery, and installation and programming if you need them.

Yes. 1Install is an authorised Crestron Elite Partner with offices in Skerries, Co. Dublin and Cork. We can supply the HD-MD4X2-4KZ on its own, or install, set up and programme it as part of your system. Installation visits are €440 for 4 hours or €880 for a full day, plus VAT and travel.

Yes. Everything we supply is new, genuine Crestron with Crestron's standard warranty. If the HD-MD4X2-4KZ develops a fault, contact us and we will handle the claim with Crestron. If we installed it, our workmanship is guaranteed for the lifetime of the system.

We order Crestron for each quote, so availability depends on Crestron's stock at the time. We check it before we quote and put the expected delivery date on your quote, so you know where you stand before you pay.

Yes. We supply Crestron to end users, with or without installation. If you are not sure it suits your system, send us the part numbers you already have and we will check.
