Crestron SSW-100-EL-USB Wall Room Availability Sign, No Engraving

It is a wall mount room availability hall sign kit. It contains the SSW-100-EL enhanced legibility sign, supplied without engraving, and an ADPT-USB-USB-RA USB-C to USB-A adapter. The sign lights green or red to show whether a room is available and is clearly visible from up to 46 m (150 ft).

Both are wall mount room availability sign kits that include the ADPT-USB-USB-RA adapter. Crestron describes the SSW-100-EL-USB KIT as supplied without engraving, while the SSW-102-EL-USB KIT includes custom engraving of one or two lines of text, or a graphical icon, on each side.

It connects over USB 2.0 to TSW-70 and TSW-80 series touch screens used for room scheduling. The ADPT-USB-USB-RA adapter needed for an 80 series panel is included. The sign also supports Cresnet client mode, so a Crestron control system can drive it for custom functions.

It takes power from its connection. On USB power it uses 1.2 W at 5 V, and on Cresnet it uses 2.4 W at 24 VDC. Heat dissipation is 4 BTU/hr on USB power or 7 BTU/hr on Cresnet, and it operates from 5°C to 45°C.

It mounts to the wall over a 1-gang electrical box or plaster ring. The sign measures 163 mm high, 71 mm wide and 218 mm deep and projects 214 mm (8.43 in) from the wall. It is built on a metal bracket with a replaceable grey acrylic face and a magnetically held grey plastic bezel.

Crestron's advertised price for the SSW-100-EL-USB in Ireland is €293 plus VAT, which is €360.39 including VAT at 23%. It does not include delivery, installation or programming, which we quote separately. Tap Request a quote for a written quote.

Yes. 1Install is an authorised Crestron Elite Partner with offices in Skerries, Co. Dublin and Cork. We can supply the SSW-100-EL-USB on its own, or install, set up and programme it as part of your system. Installation visits are €440 for 4 hours or €880 for a full day, plus VAT and travel.

Yes. Everything we supply is new, genuine Crestron with Crestron's standard warranty. If the SSW-100-EL-USB develops a fault, contact us and we will handle the claim with Crestron. If we installed it, our workmanship is guaranteed for the lifetime of the system.

We order Crestron for each quote, so availability depends on Crestron's stock at the time. We check it before we quote and put the expected delivery date on your quote, so you know where you stand before you pay.

Yes. We supply Crestron to end users, with or without installation. Like most Crestron devices of this type, it needs setting up or programming before it works in a system, and we can quote for that too.
