Crestron ZUMNET-DIN-DLI Zum DIN Rail DALI-2 Lighting Controller

It is a DIN rail mounted Zum wired lighting controller for DALI drivers. It is DALI-2 certified, supports 64 DALI drivers and 16 DALI groups, and connects to Zum Net devices for network expansion and to Zum Link devices for in-room control.

Crestron lists 64 DALI drivers and 16 DALI groups. The controller has a DALI bus power supply rated 0.23A maximum and 0.17A guaranteed, and its DA- and DA+ spring clamp terminals each accept one 12-24 AWG solid wire.

It connects over Ethernet to a ZUM-HUB4 control system and integrates with Zum keypads, presence detectors and daylight sensors, all sold separately. Two ZUMNET RJ-45 ports handle the control system or Zum Net connection and further daisy-chaining, and two ZUMLINK RJ-45 ports daisy-chain in-room Zum Link devices.

Yes. Alongside DALI control, it has a switched output, wired through the N, L and Out terminal block, rated 16A at 100-277V AC, 50/60 Hz, and 1 HP at 120-277V AC. The switch is rated for 100,000 on/off operations at 16A, 277V AC.

It is 4 modules wide on DIN rail, and the light grey polycarbonate housing measures 94 mm high, 71 mm wide and 59 mm deep. It is rated for a local in-cabinet air temperature of 0 to 55 °C and dissipates between 5 and 14 BTU/hr, depending on DALI loading and passthrough current.

Crestron asks its dealers to give the price of the ZUMNET-DIN-DLI directly rather than publish it online. Add it to your quote list and we will send you a written quote, with delivery, and installation and programming if you need them.

Yes. 1Install is an authorised Crestron Elite Partner with offices in Skerries, Co. Dublin and Cork. We can supply the ZUMNET-DIN-DLI on its own, or install, set up and programme it as part of your system. Installation visits are €440 for 4 hours or €880 for a full day, plus VAT and travel.

Yes. Everything we supply is new, genuine Crestron with Crestron's standard warranty. If the ZUMNET-DIN-DLI develops a fault, contact us and we will handle the claim with Crestron. If we installed it, our workmanship is guaranteed for the lifetime of the system.

We order Crestron for each quote, so availability depends on Crestron's stock at the time. We check it before we quote and put the expected delivery date on your quote, so you know where you stand before you pay.

Yes. We supply Crestron to end users, with or without installation. Like most Crestron devices of this type, it needs setting up or programming before it works in a system, and we can quote for that too.
