Crestron FT2A-PWR-UN-2 Dual Universal AC Outlet Module

Crestron part number FT2A-PWR-UN-2

The Crestron FT2A-PWR-UN-2 is the dual universal AC power outlet module for the Crestron FT2 Series FlipTop cable management system. Crestron describes it as providing four universal outlets, two above the table and two below, for laptops and other AC powered devices.

Price on request

The price isn't hidden. Crestron asks its dealers to share it with you directly rather than publish it online, so tap Request a quote and we'll send it straight to you.

Qty

Prefer to talk? Dublin 01 906 9326 Cork 021 202 8107 WhatsApp us

Installation and programming

Need it installed? Our Crestron certified engineers install, set up and programme everything we supply. A 4 hour visit is €440 and a full day €880, plus VAT.

Book an installation

Crestron FT2A-PWR-UN-2 AC Power Outlet Module for FT2 Series, Dual, Universal

About the Crestron FT2A-PWR-UN-2

The two outlets above the table sit nearly flush at the top of the FlipTop for easy access, and two more are provided below the table. All four are universal outlets, which Crestron lists as suitable where Type B, F, G or I power outlets are used, and the module is rated 10 A at 120-240 VAC, 50/60 Hz.

Although it is named as the dual module, it occupies four consecutive module slots within the FlipTop chassis, twice the space of the single outlet versions. It is a simple drop-in design in precision-fit black plastic. When adding one to an existing FlipTop, or swapping it in for a single outlet module, check that four neighbouring slots are available.

Crestron specifies the module for an operating temperature of 0° to 45° C (32° to 113° F) and 10% to 90% RH, non-condensing, and its compliance listing is WEEE. If you are replacing a unit, order the same part number so the FlipTop keeps all four outlets and the same slot layout.

Key features

Four universal AC power outlets for an FT2 Series FlipTop
Two outlets above the table and two below
Top outlets sit nearly flush with the FlipTop
Listed for use where Type B, F, G or I power outlets are used
Rated 10 A at 120-240 VAC, 50/60 Hz
Drop-in module using four consecutive slots

FT2A-PWR-UN-2 specifications

Outlets	4 x universal AC outlets: 2 above the table, 2 below
Outlet types	For use where Type B, F, G or I power outlets are used
Power rating	10 A @ 120-240 VAC, 50/60 Hz
For use with	Crestron FT2 Series FlipTop cable management system
Mounting	Drop-in; requires four consecutive module slots in the FlipTop chassis
Construction	Precision-fit plastic drop-in module, black
Environment	0° to 45° C (32° to 113° F); 10% to 90% RH (non-condensing)
Compliance	WEEE

Part numbers on this page

Part number	Version	Price	Add
FT2A-PWR-UN-2	Dual universal	On request

Where the FT2A-PWR-UN-2 is used

Meeting tables that need more than one AC outlet
Tables that need power both above and below the surface
Sites where Type B, F, G or I power outlets are used
Replacing a dual universal module in an existing FT2 Series FlipTop

Crestron installed by 1Install

We supply, install and programme Crestron in homes and businesses across Ireland. These photos are from our own installations. See more in our projects, or budget a whole system with our Quote Builders for homes and meeting rooms.

Questions about the Crestron FT2A-PWR-UN-2

What is the Crestron FT2A-PWR-UN-2?

It is the dual universal AC power outlet module for Crestron's FT2 Series FlipTop cable management system. Crestron describes it as providing four universal outlets in total, with two above the table and two below, for laptops and other AC powered devices.

Why does the FT2A-PWR-UN-2 have four outlets if it is called dual?

The product is named as the dual universal module, and Crestron's description explains that it provides two outlets above the table and two additional outlets below the table. That gives four universal AC outlets from one module.

How many FlipTop slots does the FT2A-PWR-UN-2 need?

It needs four consecutive module slots within the FlipTop chassis, twice the space of the single outlet modules. Check that four neighbouring slots are free before fitting it into an existing FlipTop.

What is it rated for?

The outlets are rated 10 A at 120-240 VAC, 50/60 Hz. The module is specified for 0° to 45° C (32° to 113° F) and 10% to 90% relative humidity, non-condensing, and its compliance listing is WEEE.

Which outlet types is it listed for?

Crestron lists the universal outlets as suitable for use where Type B, F, G or I power outlets are used. That is a wider list than the single universal module, which Crestron lists for Type B, G or I.

How much is the Crestron FT2A-PWR-UN-2?

Crestron asks its dealers to give the price of the FT2A-PWR-UN-2 directly rather than publish it online. Add it to your quote list and we will send you a written quote, with delivery, and installation and programming if you need them.

Can 1Install supply, install and programme the FT2A-PWR-UN-2?

Yes. 1Install is an authorised Crestron Elite Partner with offices in Skerries, Co. Dublin and Cork. We can supply the FT2A-PWR-UN-2 on its own, or install, set up and programme it as part of your system. Installation visits are €440 for 4 hours or €880 for a full day, plus VAT and travel.

Does the FT2A-PWR-UN-2 come with a warranty?

Yes. Everything we supply is new, genuine Crestron with Crestron's standard warranty. If the FT2A-PWR-UN-2 develops a fault, contact us and we will handle the claim with Crestron. If we installed it, our workmanship is guaranteed for the lifetime of the system.

Is the FT2A-PWR-UN-2 in stock?

We order Crestron for each quote, so availability depends on Crestron's stock at the time. We check it before we quote and put the expected delivery date on your quote, so you know where you stand before you pay.

Can I buy the FT2A-PWR-UN-2 without installation?

Yes. We supply Crestron to end users, with or without installation. If you are not sure it suits your system, send us the part numbers you already have and we will check.
